Hydraulic and Transmission Oils
Agrimax JDF Tractor Transmission Fluid
Liquimatic JDF is a hydraulic / transmission fluid, formulated with high quality mineral oils and specialised additives for use in agricultural, plant and material handling equipment.
This grade provides anti-wear and extreme pressure (EP) protection to gear systems, including transmissions and
final drives, as well as ensuring that hydraulic system integrity is maintained.
Additionally, Liquimatic JDF has superior wet (oil immersed) brake performance, assisting in the elimination of “squawk and chatter” and therefore prolonging the life of frictional materials and other components.
The additive system also provides superior resistance to oxidation, rust and corrosion, together with improved antifoam performance.
Agrimax Super Farm Uni 10W/30 (400hrs)
Super Farm Universal has been designed to cover the majority of agricultural lubrication requirements, whilst maintaining a reduced inventory. This grade is formulated with the latest additive technology and high quality mineral oils to produce a universal lubricant for tractors, combines and agricultural machinery subjected to the severest of operating conditions.
Super Farm Universal 10W/30 (400hrs)
Super Farm Universal has been designed to cover the majority of agricultural lubrication requirements, whilst maintaining a reduced inventory. This grade is formulated with the latest additive technology and high quality mineral oils to produce a universal lubricant for tractors, combines and agricultural machinery subjected to the severest of operating conditions.
Applications
ENGINES: Suitable for 4-four stroke naturally aspirated and turbocharged diesel engines, where it provides the highest standards of engine cleanliness and component protection. Low temperature fluidity helps overcome starting problems for exposed farm equipment and
protects against wear from start up, right through to the highest operating temperatures.
HYDRAULICS: Performs extremely well in all hydraulic systems where it protects pumps, system components
and rams against wear and corrosion right through the extremes of operating conditions and temperatures.
A special anti-foam additive is incorporated to release entrained air and help prevent sponginess in system operation. This oil has also been designed for use in hydrostatic transmissions on equipment where a universal product is recommended by the manufacturer.
TRANSMISSIONS: Designed for coping with shock loads and provide high load bearing protection for gears and other components. It is also recommended for farm tractors and other plant where the transmission contains
oil immersed or “wet brakes”. This oil has been formulated to reduce the tendency for the brakes to “squawk and chatter”, whilst protecting brake system components.
Performance Levels
Recommended for use in equipment calling for the following specifications and performance levels.
ENGINE
API CG-4
MAN 271
MIL-L-2104D
CCMC D4
MB 228.1
Ford M2C-121B
STOU SPECIFICATIONS
MF M-1139
MF M-1144
MF M-1145
Ford M2C 159B
John Deere JDM J27
ZF TE-ML 06,07
NH No 8200 9201
TRANSMISSION AND GEAR
API GL-4 (L-20)
Allison C4
Cat TO-2
Low speed / High Torque
(L-37) with broken in gears
UNIVERSAL TRANSMISSION
MF M1135
John Deere J20C
Ford M2C 134D
(New Holland NH – 410B)
Case-IH MS 1207*, 1209*
Triad 32
Premium Mineral Based Hydraulic Oil - 5Ltr is a genuine mineral-based hydraulic fluid from Morris Lubricants, formulated to protect and optimise hydraulic systems that specify ISO VG 32 oil. Supplied in a 5 litre pack, it provides reliable lubrication for pumps, valves and cylinders in mobile plant, construction equipment, agricultural machinery and industrial machinery. Its balanced anti-wear and corrosion-inhibiting additives help reduce component wear, while anti-foam and rapid air release properties support smooth, consistent control with a responsive feel at the lever. Designed for year-round use in UK conditions, it helps keep systems efficient and free from sponginess. Manufacturer Part Number (MPN): 867 100. Genuine Part for users who want dependable performance and straightforward maintenance.
Key Features:
ISO VG 32 mineral-based hydraulic oil for systems requiring a light viscosity grade
Excellent anti-wear protection to help extend pump and component life
Effective corrosion inhibition to guard internal surfaces and reduce rust formation
Superior anti-foam performance for stable operation and reduced aeration
Rapid air release to improve responsiveness and minimise spongy control
Helps maintain consistent performance under demanding, stop-start and heavy-duty use
Good oxidation resistance to support oil cleanliness and service life
Smooth cold start behaviour typical of ISO 32 grades for faster system readiness
Suitable for mixed fleets where multiple machines require ISO VG 32 hydraulic oil
Genuine Part from Morris Lubricants, MPN 867 100
Typical Applications:
Use in hydraulic systems on excavators, telehandlers, loaders, mini diggers, skid steers, compactors, forestry and agricultural equipment, log splitters, presses and other industrial plant that specifies ISO VG 32 oil. Ideal for mobile plant operating on site or in the yard where dependable control and protection are required. Suitable for power packs, hydraulic rams and systems with fine filtration where air release and anti-foam are important.
Also known as:
AW32 hydraulic oil, HLP 32, 32 grade hydraulic oil, light hydraulic fluid, anti-wear hydraulic oil, ISO 32 hydraulic oil, 32 weight hydraulic oil.
Triad 46
Morris Triad 46 Hydraulic Oil - 5L is a premium, mineral-based hydraulic fluid from Morris Lubricants designed to protect and lubricate hydraulic pumps, valves and actuators in both mobile and stationary systems. With an ISO VG 46 viscosity grade, it delivers stable performance across typical operating temperatures while maintaining efficient power transfer. Its anti-wear formulation helps reduce component wear, and inhibitors guard against rust, corrosion and oxidation, supporting clean, reliable operation. An effective anti-foam package promotes rapid air release to maintain smooth movement and consistent response. Supplied as a Genuine Part in a 5 litre container, it is suitable for mobile plant, agricultural and forestry equipment, workshop presses, power packs and log splitters used in demanding environments.
Key Features:
ISO VG 46 mineral-based hydraulic oil for balanced protection and efficiency
Excellent anti-wear properties to help protect vane, piston and gear pumps
Rust, corrosion and oxidation inhibited to reduce deposits and extend service life
Anti-foam additives for rapid air release and smooth, consistent system response
Stable viscosity for dependable performance in varied operating conditions
Helps minimise downtime by supporting reliable operation in demanding duty cycles
Suitable for a wide range of mobile plant, industrial and forestry hydraulic systems
Genuine Morris Lubricants product for quality you can trust
Typical Applications:
Designed for hydraulic circuits in mobile plant (excavators, loaders, dumpers), agricultural machinery with auxiliary hydraulics, forestry kit and log splitters, industrial presses, power packs, compactors, tail lifts and materials-handling equipment. Well suited to workshops maintaining mixed fleets where a robust ISO VG 46 anti-wear hydraulic oil is specified for day-to-day operation.
Also known as:
Hydraulic fluid 46, AW46 hydraulic oil, HLP 46, ISO 46 hydraulic oil, VG46 hydraulic fluid, anti-wear hydraulic oil 46, mineral hydraulic oil 46. Commonly used wherever an ISO VG 46 anti-wear mineral hydraulic oil is specified by the equipment manufacturer.
Alternate Part Numbers:
867 900, 867-900, 867900
Liquimatic HV46
Morris Liquimatic HV46 Oil - 5L is a high-performance hydraulic oil crafted by Morris Lubricants. It is formulated with a high viscosity index and features advanced anti-wear technology, ensuring reliable operation in diverse climates, from -20°C to high heat. The shear-stable formula maintains viscosity, making it ideal for demanding hydraulic systems. This 5-litre oil protects against rust, corrosion, and oxidation, including resistance in seawater environments. Designed for use in industrial and off-highway machinery, this oil serves critical components such as hydrostatic drives, power steering, and brake systems.
Key Features:
High viscosity index for consistent performance
Advanced anti-wear technology
Operates in temperatures from -20°C upwards
Shear-stable formula resists thinning
Protection against rust and corrosion
Resists oxidation, even in seawater
Excellent filterability and thermal stability
Anti-foam properties for efficient operation
Suitable for industrial and off-highway hydraulic systems
5-litre capacity for extended use
Typical Applications:
Ideal for industrial and off-highway applications such as contractor’s plant and machinery, hydrostatic drives, power steering, and brake systems. Suitable for environments requiring a reliable hydraulic oil that withstands temperature extremes and provides extended equipment protection.
Also known as:
Hydraulic oil, HV46 hydraulic fluid, anti-wear hydraulic oil, Morris HV46 hydraulic lubricant, high viscosity index oil.
LIQUIMATIC NO1 ISO VG10
Ashless Hydraulic Oil
The Morris Liquimatic range of high quality hydraulic oils are formulated with Group II base fluids, incorporating ashless additive technology and available in a variety of viscosity grades. They are rust and oxidation inhibited and will provide protection against corrosion even in the presence of seawater. Excellent anti-wear properties provide protection against wear in the most demanding of systems. The presence of effective anti-foam additives facilitate the rapid release of air and reduce sponginess in system operation. These hydraulic oils meet the stringent filterability requirements of modern hydraulic machines and robotics. Group II base oil technology ensures reduced evaporation losses in high temperature applications, particularly with the lower viscosity grades and improved deposit control in critical valve gear.
Features
Zinc free, ashless additive
Rapid air release properties
Excellent water separation properties
Excellent thermal stability
Long oil life
Excellent filterability
Compatible with all bronze, silver and steel system parts
Applications
Recommended for both Industrial and off highway hydraulic systems. Other applications include: machining centre headstocks, centralised lubrication systems, hydrostatic drives, power steering, compressors, suspension units, tipping gear, airline lubricators, jacks, PTOs, et cetera where long life and good filterability is required.
Liquimatic No 2 ISO 15 Hydraulic Oil
An ISO VG 15 high quality hydraulic oil formulated with Group II base fluids, incorporating ashless additive technology and available in a variety of viscosity grades. It is rust and oxidation inhibited and will provide protection against corrosion even in the presence of seawater. Excellent anti-wear properties provide protection against wear in the most demanding of systems. It also contains an effective anti-foam additive to facilitate the rapid release of air and reduce sponginess in system operation. This hydraulic oils meet the stringent filterability requirements of modern hydraulic machines and robotics.
Group II base oil technology ensures reduced evaporation losses in high temperature applications, particularly with the lower viscosity grades and improved deposit control in critical valve gear
Key Features & Specification
Rapid air release
Zinc Free, ashless additive
Long oil life
Excellent filterability
Compatible with all Bronze, Silver and Steel system parts
Latest anti-wear and EP technology
Good thermal stability
Applications
Recommended for both Industrial and off highway hydraulic systems. Other applications include: machining centre headstocks, centralised lubrication systems, hydrostatic drives, power steering, compressors, suspension units, tipping gear, airline lubricators, jacks, PTOs
Liquimatic No 3 ISO 22 Hydraulic Oil
An ISO VG 22 high quality hydraulic oil formulated with Group II base fluids, incorporating ashless additive technology and available in a variety of viscosity grades. It is rust and oxidation inhibited and will provide protection against corrosion even in the presence of seawater. Excellent anti-wear properties provide protection against wear in the most demanding of systems. It also contains an effective anti-foam additive to facilitate the rapid release of air and reduce sponginess in system operation. This hydraulic oils meet the stringent filterability requirements of modern hydraulic machines and robotics.
Group II base oil technology ensures reduced evaporation losses in high temperature applications, particularly with the lower viscosity grades and improved deposit control in critical valve gear
Key Features & Specification
Rapid air release
Zinc Free, ashless additive
Long oil life
Excellent filterability
Compatible with all Bronze, Silver and Steel system parts
Latest anti-wear and EP technology
Good thermal stability
Applications
Recommended for both Industrial and off highway hydraulic systems. Other applications include: machining centre headstocks, centralised lubrication systems, hydrostatic drives, power steering, compressors, suspension units, tipping gear, airline lubricators, jacks, PTOs
Liquimatic No 4 ISO 32 Hydraulic Oil
An ISO VG 32 high quality hydraulic oil formulated with Group II base fluids, incorporating ashless additive technology and available in a variety of viscosity grades. It is rust and oxidation inhibited and will provide protection against corrosion even in the presence of seawater. Excellent anti-wear properties provide protection against wear in the most demanding of systems. It also contains an effective anti-foam additive to facilitate the rapid release of air and reduce sponginess in system operation. This hydraulic oils meet the stringent filterability requirements of modern hydraulic machines and robotics.
Group II base oil technology ensures reduced evaporation losses in high temperature applications, particularly with the lower viscosity grades and improved deposit control in critical valve gear
Key Features & Specification
Rapid air release
Zinc Free, ashless additive
Long oil life
Excellent filterability
Compatible with all Bronze, Silver and Steel system parts
Latest anti-wear and EP technology
Good thermal stability
Applications
Recommended for both Industrial and off highway hydraulic systems. Other applications include: machining centre headstocks, centralised lubrication systems, hydrostatic drives, power steering, compressors, suspension units, tipping gear, airline lubricators, jacks, PTOs
Liquimatic No 5 ISO 46 Hydraulic Oil
An ISO VG 46 high quality hydraulic oil formulated with Group II base fluids, incorporating ashless additive technology and available in a variety of viscosity grades. It is rust and oxidation inhibited and will provide protection against corrosion even in the presence of seawater. Excellent anti-wear properties provide protection against wear in the most demanding of systems. It also contains an effective anti-foam additive to facilitate the rapid release of air and reduce sponginess in system operation. This hydraulic oil meets the stringent filterability requirements of modern hydraulic machines and robotics.
Group II base oil technology ensures reduced evaporation losses in high temperature applications, particularly with the lower viscosity grades and improved deposit control in critical valve gear
Key Features & Specification
Rapid air release
Zinc Free, ashless additive
Long oil life
Excellent filterability
Compatible with all Bronze, Silver and Steel system parts
Latest anti-wear and EP technology
Good thermal stability
Applications
Recommended for both Industrial and off highway hydraulic systems. Other applications include: machining centre headstocks, centralised lubrication systems, hydrostatic drives, power steering, compressors, suspension units, tipping gear, airline lubricators, jacks, PTOs
Liquimatic No.6
Morris Lubricants Liquimatic No.6 ISO 46 Hydraulic Oil is a zinc-free, ashless anti-wear hydraulic fluid supplied in a 25 litre container. It is formulated to protect and lubricate hydraulic pumps, valves and actuators in industrial plant and off-highway machinery. The ashless package is compatible with bronze, silver and steel components, helping to minimise corrosion and staining of yellow metals while maintaining clean system operation. Its ISO VG 46 viscosity supports stable film strength and smooth response across typical operating temperatures. Suitable for machining centre headstocks, centralised lubrication systems, hydrostatic drives and power steering circuits, it provides dependable wear protection under high loads and helps maintain efficient, long-lasting hydraulic performance in construction, agricultural and workshop equipment.
Key Features:
Zinc-free, ashless anti-wear formulation to protect sensitive yellow metals
EP performance reduces wear in heavily loaded vane, gear and piston pumps
Good oxidation stability for long oil life and reduced varnish formation
Fast air release and foam control for quiet, responsive hydraulics
Effective rust and corrosion inhibition for steel and non-ferrous parts
Good demulsibility to separate water and maintain lubrication integrity
Reliable filterability for fine-element and centralised lube systems
Stable ISO VG 46 viscosity for consistent performance
Broad equipment suitability: industrial and off-highway hydraulic systems
Compatible with machining centre headstocks and hydrostatic transmissions
25 litre pack size suits workshops and on-site maintenance
Typical Applications:
Industrial power packs, injection moulding machines, machine tool headstocks and centralised lubrication systems. Off-highway hydraulics on excavators, loaders, telehandlers and tractors. Hydrostatic drives, power steering circuits, compressors requiring hydraulic oils, suspension units, tipping gear, airline lubricators, jacks and PTO-driven hydraulic systems.
Also known as:
Morris Liquimatic hydraulic fluid, hydraulic oil VG 46, ashless AW hydraulic oil 25L, industrial hydraulic lubricant ISO 46, 25 litre hydraulic system oil.
Alternate Part Numbers:
977-2044, 9772044, LIQ025
Liquimatic No 7 ISO 100 Hydraulic Oil
An ISO VG 100 high quality hydraulic oil formulated with Group II base fluids, incorporating ashless additive technology and available in a variety of viscosity grades. It is rust and oxidation inhibited and will provide protection against corrosion even in the presence of seawater. Excellent anti-wear properties provide protection against wear in the most demanding of systems. It also contains an effective anti-foam additive to facilitate the rapid release of air and reduce sponginess in system operation. This hydraulic oil meets the stringent filterability requirements of modern hydraulic machines and robotics.
Group II base oil technology ensures reduced evaporation losses in high temperature applications, particularly with the lower viscosity grades and improved deposit control in critical valve gear
Key Features & Specification
Rapid air release
Zinc Free, ashless additive
Long oil life
Excellent filterability
Compatible with all Bronze, Silver and Steel system parts
Latest anti-wear and EP technology
Good thermal stability
Applications
Recommended for both Industrial and off highway hydraulic systems. Other applications include: machining centre headstocks, centralised lubrication systems, hydrostatic drives, power steering, compressors, suspension units, tipping gear, airline lubricators, jacks, PTOs
Liquimatic No 8 ISO 150 Hydraulic Oil
An ISO VG 150 high quality hydraulic oil formulated with Group II base fluids, incorporating ashless additive technology and available in a variety of viscosity grades. It is rust and oxidation inhibited and will provide protection against corrosion even in the presence of seawater. Excellent anti-wear properties provide protection against wear in the most demanding of systems. It also contains an effective anti-foam additive to facilitate the rapid release of air and reduce sponginess in system operation. This hydraulic oil meets the stringent filterability requirements of modern hydraulic machines and robotics.
Group II base oil technology ensures reduced evaporation losses in high temperature applications, particularly with the lower viscosity grades and improved deposit control in critical valve gear
Key Features & Specification
Rapid air release
Zinc Free, ashless additive
Long oil life
Excellent filterability
Compatible with all Bronze, Silver and Steel system parts
Latest anti-wear and EP technology
Good thermal stability
Applications
Recommended for both Industrial and off highway hydraulic systems. Other applications include: machining centre headstocks, centralised lubrication systems, hydrostatic drives, power steering, compressors, suspension units, tipping gear, airline lubricators, jacks, PTOs
Performance Levels
Liquimatic DII Transmission Fluid
Liquimatic DII is an automatic transmission fluid blended from highly refined mineral oils and a high performance additive system. It is designed to meet the performance requirements of General Motors Dexron IID specification for transmission systems built up to 1992.
This product has outstanding resistance to high temperatures encountered during severe operating conditions, and gives excellent protection against wear, rust and corrosion for all critical components.
It is completely compatible with all materials utilised in automatic transmissions systems, such as seals and specialised plastic parts. Liquimatic DII will ensure smooth and responsive clutch plate and brake band operation over a wide range of temperatures and work loads.
Liquimatic Super ATF (Dexron III)
Liquimatic Super ATF is an automatic transmission fluid blended from high quality mineral oil, synthetic base fluids and a balanced additive system.
This grade has superior performance in terms of frictional characteristics, seal compatibility, oxidation stability, low temperature fluidity and resistance to high temperatures encountered during its operation.
Liquimatic No 6 ISO 68 25 litre
Liquimatic No 6 is a high quality mineral oil based hydraulic oil, incorporating ashless additive technology and available in a variety of viscosity grades. This oil is rust and oxidation inhibited and will provide protection against corrosion even in the presence of seawater.
Excellent anti-wear and EP properties provide protection against wear in the most demanding of systems. It also contain an effective anti-foam additive to facilitate the rapid release of air and reduce sponginess in system operation. This hydraulic oil meets the stringent filterability requirements of modern hydraulic machines and robotics.
– Rapid air release.
– Zinc Free, ashless additive.
– Long oil life.
– Excellent filterability.
– Compatible with all Bronze, Silver and Steel system parts.
– Latest anti-wear and EP technology.
– Good thermal stability.
Liquimatic HV46 Hydraulic Oil 25 litre
Liquimatic HV46 is a high viscosity index hydraulic oil, formulated from high quality minerals oils and the latest anti-wear technology. This grade utilises a shear stable polymer that ensures that the oil does not thin down during its working life. It is ideal for hydraulic systems subjected to the very extremes of operating conditions and temperatures, from frozen food stores (-20ºC) to industrial hydraulic systems at elevated temperatures and off highway equipment.
It is rust, corrosion and oxidation inhibited and will provide protection even in the presence of seawater. Excellent anti-wear and EP properties provide protection against wear in the most demanding of systems.
Additionally, it is treated with an anti-foam additive to control foam and facilitate rapid air release, ensuring correct hydraulic function and meet the stringent filter-ability requirements of modern machines and robotics.
– Outstanding low temperature performance.
– Multigrade properties, lubrication film maintained at high temperatures.
– Excellent filterability.
– Latest anti-wear and EP technology.
– Good thermal stability.
Liquimatic HY Tractor Transmission Fluid
Liquimatic HY is a hydraulic / transmission fluid, formulated with high quality mineral oils and specialised additives for use in agricultural and plant equipment.
This oil is designed to protect transmission components, reduce brake chatter, clutch slippage and minimise final drive wear. Liquimatic HY can be used in hydraulic systems where it provides outstanding pump protection and where its high level of water tolerance reduces the likelihood of filter blocking.
The additive system also gives this oil superior resistance to oxidation, rust and corrosion, together with improved anti-foam performance.
Liquimatic No 4 ISO 32
Liquimatic No 4 is a high quality mineral oil based hydraulic oils, incorporating ashless additive technology and available in a variety of viscosity grades. This oil has rust and oxidation inhibited and will provide protection against corrosion even in the presence of seawater. it has excellent anti-wear and EP properties provide protection against wear in the most demanding of systems.
It also contain an effective anti-foam additive to facilitate the rapid release of air and reduce sponginess in system operation. This hydraulic oil meet the stringent filterability requirements of modern hydraulic machines and robotics.
– Rapid air release.
– Zinc Free, ashless additive.
– Long oil life.
– Excellent filterability.
– Compatible with all Bronze, Silver and Steel system parts.
– Latest anti-wear and EP technology.
– Good thermal stability.
