Generator Controllers

Trade & multiple order discounts available, ask for more details


DSE 3110

Manual & Auto Start Control Module

The DSE3110 is an outstanding compact control module that provides a comprehensive range of features for single-set applications.

The controller can be used in manual or auto start mode.

OVERALL SIZE:
98 mm x 79 mm x 40 mm (3.9” x 3.1” x 1.6”) PANEL CUTOUT SIZE
80 mm x 68 mm (3.1 " x 2.7")


MAXIMUM PANEL THICKNESS:
8.0 mm (0.3”)


WEIGHT: 0.16kg


PRODUCT VARIANTS:
3110-01 - Manual & Auto Start Control Module (Mpu)

Poa

DSE 335

Auto Transfer Switch Control Module

The DSE335 Automatic Transfer Switch Control Module has been expertly developed to monitor the voltage and frequency of an incoming AC supply from two different sources. These sources can be generator or mains (utility), or a combination of both.

The control module monitors Source 1 (S1) and Source 2(S2). When a failure occurs a start command is issued to the inactive source to take over the load.

The module will return the load to the mains (utility) as soon as this becomes available.

OVERALL SIZE:
240 mm x 181 mm x 42 mm (9.4” x 7.1” x 1.6”)
PANEL CUTOUT SIZE:
220 mm x 160 mm (8.7” x 6.3”)
MAXIMUM PANEL THICKNESS
8.0mm (0.3”)
WEIGHT: 0.9kg
PRODUCT VARIANTS
0335-01 - 335 Auto Transfer Switch Control Module - 12/24 Volt DC Supply

Poa

DSE 4520 MKII

Auto Mains (Utility) Failure Control Module

The DSE4520 MKII is a compact Auto Mains (Utility) Failure Control Module that has been developed to provide an outstanding range of features within a compact enclosure.
THE MODULE CAN BE CONFIGURED FOR USE AS AN AUTO START CONTROL MODULE.

OVERALL SIZE:
140 mm x 113 mm x 43 mm (5.5” x 4.4” x 1.5”)
PANEL CUTOUT SIZE:
118 mm x 92 mm (4.6" x 3.6")
MAXIMUM PANEL THICKNESS
8.0 mm (0.3”)
WEIGHT: 0.26kg
PRODUCT VARIANTS
4520-05 - 4520 Auto Mains (Utility) Failure Control Module (Ct, Rtc)

Poa

DSE 5210

Auto Start Control Module

The DSE5210 is an Automatic Start Control Module designed to automatically start and stop diesel and gas generating sets that include non electronic engines.

The module also provides excellent engine monitoring and protection features.

The module has the ability to monitor under speed, over...

DISCONTINUED


DSE 5220

Auto (Mains) Utility Failure Control Module

The DSE5220 is an Automatic Mains Failure Control Module designed to automatically start and stop diesel and gas generating sets that include non electronic engines.

The module also provides excellent engine monitoring and protection features.

The module has the ability to monitor under speed,...

DISCONTINUED


DSE 7120MKII

Auto Mains (Utility) Failure Control Modules

The DSE7120 is an Auto Mains (Utility) Failure Control Module with an icon-based display.

The control module has been designed to control single diesel or gas gen-set applications.

Poa

DSE 5310

Auto Start Control Module

The DSE5310 is an Automatic Start Control Module designed to automatically start and stop diesel and gas generating sets that include non electronic and electronic engines. The module also provides advanced engine monitoring and protection features.

The module has the ability to monitor under...

DISCONTINUED

DSE 6120 MKIII

Auto Mains (Utility) Failure Control Module

The DSE6120 MKIII is an Auto Mains (Utility) Failure Control Module suitable for a wide variety of single, diesel or gas, genset applications.

Monitoring an extensive number of engine parameters, the module will display warnings, shutdown and engine status information on the back-lit LCD screen, illuminated LEDs and remote PC.

The module is compatible with electronic (CAN) and non-electronic (magnetic pick-up/alternator sensing) engines and offers an extensive number of flexible inputs, outputs and extensive engine protections so the system can be easily adapted to meet the most demanding industry requirements.

OVERALL SIZE:
216 mm x 158 mm x 43 mm (8.5” x 6.2” x 1.5”)
PANEL CUTOUT SIZE:
184 mm x 137 mm (7.2” x 5.3”)
MAXIMUM PANEL THICKNESS:
8.0 mm (0.3”)
WEIGHT: 0.5kg
PRODUCT VARIANTS


6120-05 - 6120 MKIII Auto Mains (Utility) Failure Control Module

Poa

DSE 7110 MKII

Auto Start Control Module

The DSE7110 MKII is an Auto Start Control Module with an icon-based display.

The control module has been designed to control single diesel or gas gen-set applications.

Poa


DSE 7310 MKII

Auto Start Control Module

The DSE7310 MKII is a powerful, new generation auto start genset control module with a highly sophisticated level of new features and functions, presented in the usual DSE user-friendly format. Suitable for a wide variety of single, diesel or gas Gen-set applications.

OVERALL SIZE:
245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")
PANEL CUTOUT SIZE:
220 mm x 160 mm (8.7" x 6.3")
MAXIMUM PANEL THICKNESS
8.0 mm (0.3")
PRODUCT VARIANTS


7310-03 - 7310 MKII Autostart Control Module

Poa


DSE 7320 MKII

Auto Mains (Utility) Failure Control Module

The DSE7320 MKII is a powerful, new generation Auto Mains (Utility) Failure genset control module with a highly sophisticated level of new features and functions, presented in the usual DSE user-friendly format. Suitable for a wide variety of single, diesel or gas Gen-set applications.

OVERALL SIZE:
245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")
PANEL CUTOUT SIZE:
220 mm x 160 mm (8.7" x 6.3")
MAXIMUM PANEL THICKNESS
8.0 mm (0.3")
PRODUCT VARIANTS
7320-03 - 7320 MKII Auto Mains (Utility) Failure Control Module

Poa


DSE 8610 MKII

Synchronising & Load Sharing Auto Start Control Module

The DSE8610 MKII represents the latest in complex load sharing & synchronising control technology. Designed to handle the most complex grid type generator applications the DSE8610 MKII control module is packed with multiple features and benefits that are unrivalled across the generator control industry.
New Features Added May 2020. Read Product Change Notification Document for details.
Calculating Fuel Efficiency and Meeting Green Emission Directives Paper

OVERALL SIZE
245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")
PANEL CUTOUT SIZE:
220 mm x 160 mm (8.7" x 6.3")
MAXIMUM PANEL THICKNESS:
8.0 mm (0.3")

WEIGHT: 0.88kg

PRODUCT VARIANTS:


8610-02 - 8610 MKII Synchronising & Load Sharing Control Module (Ct, Rtc)

Poa


DSE 8620 MKII

Synchronising Auto Mains (Utility) Failure Load Share Control Module

The DSE8620 MKII represents the latest in complex load sharing & synchronising control technology.

Designed to synchronise a single genset with a mains (utility) supply, the DSE8620 MKII control module is packed with multiple features and benefits that are unrivalled across the generator control industry.
The controller also has the option to be configured for use as a DSE8610 MKII Auto Start Load Sharing & Synchronising Control Module. When converted for use as a DSE8610 MKII the unit provides generator to generator load share functionality.

OVERALL SIZE:
245 mm x 184 mm x 51 mm (9.6" x 7.2" x 2.0")
PANEL CUTOUT SIZE:
220 mm x 160 mm (8.7" x 6.3")
MAXIMUM PANEL THICKNESS
8.0 mm (0.3")

WEIGHT: 0.88kg

PRODUCT VARIANTS
8620-02 - 8620 MKII Synchronising Auto Mains (Utility) Failure Load Sharing Control Module

Poa


DSE 9150

12 volt 3 amp Compact Battery Charger

The DSE9150 12 volt 3 amp Switch-Mode

Battery Charger keeps batteries charged to their maximum capacity at all times.

It is designed for permanent battery connection and can be DIN rail or chassis mounted. The charger includes a normal or overload condition LED indicator on the front to assist with status identification, operates during cranking and running and accepts multiple AC voltage connections.



OVERALL SIZE:
108 mm x 101 mm x 49 mm (4.2” x 4.0” x 1.9”)
WEIGHT: 0.16kg
PRODUCT VARIANTS


9150-00 - 12 volt 3 amp Compact Battery Charger (90v-265v 50/60Hz)

Poa


DSE 9255

24 Volt 5 Amp Compact Battery Charger

The DSE9255 24 volt 5 amp Switch-Mode Battery Charger keeps batteries charged to their maximum capacity at all times. It is designed for permanent battery connection and can be DIN rail or chassis mounted.

The charger includes a normal or overload condition LED indicator on the front to assist with status identification, operates during cranking and running and accepts multiple AC voltage connections.

OVERALL SIZE:
136 mm x 140 mm x 63 mm (5.4” x 5.5” x 2.5”)
WEIGHT: 0.5kg
PRODUCT VARIANTS


9255-00 - 24 volt 5 amp Compact Battery Charger (90-305v 50/60Hz)

Poa

Deep Sea Electronics is one of the world’s top manufacturers of generator controllers, auto transfer switch controllers, battery chargers and vehicle & off-highway controllers.



They employ over 200 people across four continents and sell our products to 150 countries direct from their UK head office and through our comprehensive distributor network.

Throughout their 40-year history, they have invested heavily in people, processes and research & development to ensure DSE continues to enhance its reputation across world markets.

DSE has UK manufacturing and engineering facilities to be proud of.

They develop and manufacture a range of over 140 different products that provide flexible control solutions for multiple applications.

INNOVATIVE IDEAS.


INFINITE POSSIBILITIES.

DSE never stop generating ideas for new products and are always looking at ways to improve.

The integration of technology and the benefits it creates drives them to succeed.

DSE want to make our products work better for their customers and have a research and development team constantly working to achieve this.

Technology excites DSE and is at the heart of their business.

DSE software engineers, hardware engineers and procurement specialists never stop looking at what’s coming next in component, display,

processor and communication technologies to make new product concepts the best they can be.



DSE manufacture their products in one place, the United Kingdom.



Their bespoke head office facilities, consistent quality and safety standards and detailed processes guarantee premium products for use worldwide.

Their attention to detail forms part of their manufacturing culture.



DSE are focused on accuracy throughout each individual stage of the manufacturing process.



Their personnel are highly skilled and take pride in creating products to perform within the toughest environments.

Quality has been the cornerstone of their business since their journey began 40 years ago.



They are committed to continuously improving their products, services and business processes to exceed customer expectations and requirements.

To reinforce this commitment they continuously develop their skilled workforce and implement strategic supplier partnerships to support their investment in growth, sustainable business practices and continuous product innovation.

You can trust that DSE produces products of the highest possible quality.

DSE FAQ's

What size charger should I use for a battery that regularly discharges to a low level?

This usually means you require a fast recharge time.

Use a larger charger, with a current rating 10% of the Ah capacity of the battery.

For example, for a 100 Ah battery, use a charger up to 10 A.

If you want to charge at a rate more than this, check first with your battery manufacturer.

What size charger should I use for a battery that is used as a starter battery on a generator?

First consider the panel load on the battery. This is the main requirement for the charge current. The battery charger must be able to supply this current. Any remaining capacity in the charger is used to charge the battery. Battery charging only needs to be a small amount above this to keep the battery “topped up”. Bulk charging after an engine start is performed by the DC Charging Alternator. For example, for a standing load (panel load) of 2 A, a 5 A or 10 A charger is usually considered satisfactory for the majority of generator applications.

What types of batteries are compatible with DSE Battery Chargers?

DSE Battery Chargers have a configurable charging voltage suitable for most battery types (ie NiCd, Lead Acid, Gel type etc). For the “Intelligent” chargers, this voltage is PC configurable by the user.

Contact DSE Technical Support for more information.

Does my DSE battery charger need to be disconnected when the engine is running?

No, DSE battery chargers can be left connected during cranking and while the engine is running.

Is it possible to install DSE battery chargers in series to achieve a higher voltage or in parallel to achieve a higher current output?

Yes. DSE battery charger outputs can be connected in parallel for a higher current rating or in series for a higher voltage rating

Can I use DSE chargers to supply a standing panel load?

Yes. DSE chargers can be used as power supplies or as a PSU to supply a standing load

How can I prevent Fail to Stop on the DSE ATS controller when the generator is run from its local controls?

DSE334 and DSE335 have the option to disable the Fail to Stop detection using the DSE Configuration Suite PC Software.

Which ATS controller is most suited for a system with two mains supplies to select one available supply from two?

DSE334 and DSE335 are designed specifically to support this application.

My cooling timer has expired but my engine is still running. What should I do?

Check the cooling timer in the Genset controller is suitable for the application.

Do I need to fit breaker auxiliary contacts to my DSE ATS Controller?

The installation of auxiliary contacts is optional with the DSE 33X range of controllers.

If the contactor auxiliary contacts are not fitted to the modules inputs, the on load indication lamps will follow whichever load contactor is closed

My synchronising system doesn’t sync and/or load share correctly. What should I do?

Ensure the DSE Four Steps to Synchronising procedure has been followed correctly.

Contact DSE Technical Support if you continue to have problems after performing this procedure.

Where can I find the DSE Configuration Suite Software and supporting documentation for my DSE product?

Visit the product page for the device on our website and select SOFTWARE.

All information and PC software for the device is listed here.

I’m installing the DSE Configuration Suite Software on more than one PC. Do I have to download the updates from the Internet on every computer?

When the DSE Configuration Suite is installed, two useful tools are installed automatically at the same time.

The Export Configuration tool allows you to export the update files from the first PC to an external USB drive.

The update from local source allows you to update the other computers from the USB drive.

I’ve installed the DSE Configuration Suite Software and have been asked for a username and password at the end of the installation. Where do I find this information?

When the DSE Configuration Suite Software is first installed, it runs an update check from the Internet at the end of the installation.

The update application needs to login to DSE servers to download updates and complete the installation.

The login details required for the updater are the same credentials used to login to their website.

Can I run the DSE Configuration Suite Software on Windows 10?

The DSE Configuration Suite software is compatible and designed to work with Windows 10

Can the same controller be used on a 12V and 24V DC system?

DSE controllers are designed to operate with a DC supply range of 8 V DC to 35 V DC.

Therefore, the same controller can be supplied by a 12 V or 24 V supply.

My DSE Configuration Suite Software does not recognise the DSE module/charger I have connected to my PC. What should I do?

Update your DSE Configuration Suite Software to the latest version.

Visit www.deepseaelectronics.com to do this.

I have connected my DSE module/charger to my PC via USB cable. The DSE Configuration Suite states ‘No Modules Connected’. What should I do?

Try using a different USB Port on your PC, power cycle the DSE module or restart the Configuration Suite PC Software.

If these procedures fail to resolve the issue uninstall the DSE Configuration Suite PC Software and then reinstall it.

comap logo.png

InteliLite 4 AMF 25



Order code: IL4AMF25BAA, IL4AMF25BLA

InteliLite 4 AMF 25 an advanced single gen-set controller for stand-by and prime power applications. Intuitive, flexible, easy to install and use, the InteliLite 4 AMF 25 controller offers multiple configuration options to create the best solution for controlling and monitoring your gen-sets both on-site and remotely.



  • Easy configuration with InteliConfig

  • Remote communication support

  • Cyber security by design

  • Easy troubleshooting

  • Built-in PLC logic


InteliLite 4 AMF 20



Order code: AIL4AMF20BAA

InteliLite 4 AMF 20 is an advanced single gen-set controller for stand-by and prime power applications. Intuitive, flexible, easy to install and use, the InteliLite 4 AMF 20 controller offers multiple configuration options to create the best solution for controlling and monitoring your gen-sets both on-site and remotely.


  • Easy configuration with InteliConfig

  • Remote monitoring

  • Cybersecurity by design

  • Easy troubleshooting

  • Built-in PLC logic


InteliLite 4 MRS 16



Order code: IL4MRS16BAA, IL4MRS16BLA

InteliLite 4 MRS 16 is an advanced single gen-set controller for prime power applications. Ensuring reliable prime power, the controller effectively monitors, protects, and controls the gen-set and circuit breaker to supply the load.


  • Easy configuration with InteliConfig

  • Remote monitoring

  • Cybersecurity by design

  • Reliable internet access

  • Built-in PLC logic

  • Easy troubleshooting


InteliLite 4 AMF 9



Order code: IL4AMF9XBAA

InteliLite 4 AMF 9 is a single gen-set controller for stand-by and prime power applications. Intuitive, flexible, easy to install and use, the InteliLite 4 AMF 9 controller offers multiple configuration options to create the best solution for controlling and monitoring your gen-sets on-site and remotely.


  • Easy configuration with InteliConfig

  • Remote monitoring

  • Cybersecurity by design

  • Easy troubleshooting

  • Built-in PLC logic


InteliLite 4 AMF 8



Order code: IL4AMF8XBAA

InteliLite 4 AMF 8 is a single gen-set controller for stand-by and prime power applications. Intuitive, flexible, easy to install and use, the InteliLite 4 AMF 8 controller offers multiple configuration options to create the best solution for controlling and monitoring your gen-sets on-site and remotely.


  • Easy configuration with InteliConfig

  • Remote monitoring

  • Cybersecurity by design

  • Easy troubleshooting

  • Built-in PLC logic


InteliLite LTC 90



Order code: IL4LTC90BLA

The InteliLite LTC 90 is a single gen-set controller is designed specifically for controlling light tower applications. Easy and automated control for your light towers whenever you need it, this controller can operate in low temperatures and offers automatic light management, remote management, and reliable cyber security protection to optimise the operations of your light power source.


  • Automatic lights activation

  • Lamp management system

  • Low temperature operation

  • Reliable remote communication & monitoring

  • Cybersecurity by design


InteliLite LTC 80



Order code: IL4LTC80BAA

The InteliLite LTC 80 is a single gen-set controller is designed specifically for controlling light tower applications. Easy and automated control for your light towers whenever you need it, this controller offers automatic light management, remote management and reliable cyber security protection to optimise the operations of your light power source.


  • Automatic lights activation

  • Lamp management system

  • Reliable remote communication & monitoring

  • Cybersecurity by design


InteliLite TELECOM



Order code: IL2TLCXXAAA

The InteliLite Telecom is an Auto Mains Failure (AMF) gen-set controller designed specifically for mobile operators and telecom tower companies. Ready to respond to the demands of telecommunications organisations, the controller provides remote monitoring and control via ComAp’s cloud-based WebSupervisor tool, complex battery charging management, and comes with a wide range of features that help optimise predictive maintenance and reduce operational costs.


  • Dual AMF support

  • Support for MRS applications

  • Remote monitoring

  • Smart battery charging and cycling management

  • EFI engine support


PowerWizard 1.0
Total control at the touch of a button!
FG Wilson’s new range of digital control panels gives you the industry leading control solution for all your power needs.
The PowerWizard 1.0 control system offers a cost effective way of monitoring and communicating with your generating set.
Using cutting edge technology we’ve integrated meters, gauges and dials into one display, giving you quick and easy access to controls, metering, protection device settings and diagnostic information.
Why should you choose an FG Wilson PowerWizard 1.0 series control panel?
Common look and feel from 10 to 2000 kVA for ease of operation and service 10.5-32V DC providing a single module to cover whole product range Simple menu layout for ease of navigation and monitoring Two display languages, (Customer language and Technician English*) to aid service and commissioning 20 event log to aid fault finding Robust electronics package for industry leading reliability Configurable using front key pad/laptop Shortcut keys for immediate access to engine or AC metering Integrated metering and controls reducing components and wiring, aiding reliability and ease of service Common engine wiring system allows simple upgrading between levels of panel Can be serviced using standard EST too


PowerWizard 2.1

Digital Control Panel

The FG Wilson Communications Interface Module and Software Package allows operators to monitor and control all generator set functions from a virtual control panel on their PC.

For distances up to 1,000 metres, where it is convenient to have a hard-wired connection, a generator set can be monitored using the Communications Interface Module and Software Package on the operator’s PC or laptop.

Alternatively, when laying a hard-wired connection is not convenient, the same monitoring and control functionality is available, but communication between the operator’s PC or laptop and the Control Panel is made through a modem and the telephone network.

Standard Equipment

Robust electronics package for industry leading reliability

Single menu layout for ease of navigation and monitoring with shortcut keys for immediate access to engine or AC metering.

10.5-32V DC providing a single module to cover the whole FG Wilson generator set range.

Comprehensive range of standard features and options to ensure the most appropriate configuration for your needs.

Serviced using standard EST.

Main Features

True RMS Voltage Sensing

CAN 1 Data Link for communication to electronic engines, CAN 2 (2.1 only) Accessory Data Link for additional modules.

40 unique events log configuration including first, last and number of occurances and real time clock.

Engine and AC Monitoring.

Two display languages (Customer Language & Technician Language)

Up to 5 spare fault channels.

Configurable sender input.

Dedicated key to reset all faults and main menu short cut key.

Run/Auto/Stop keys with LED indicators.

Integrated metering and controls reducing components and wiring, aiding reliability and ease of service.

Generator set voltage and over / under frequency protection.

MODBUS connection to building management system via RS485.

Power Metering.

bottom of page
